EBARA MULTIGO PUMP M40/08

EBARA MULTIGO PUMP M40/08

This is a Multigo 40/08 Vertical multistage centrifugal electric pump (AISI 304)


APPLICATIONS

• Flooded areas
• Boosting of hydraulic plants
• Fountains
• Rainwater Harvesting
• Allotments & Gardens


TECHNICAL DETAILS

• Quiet & Reliable
• Moving water cools the motor
• Durability ensured by interposed oil chamber
• Equipped with 20 metres of H07 RN-F power supply cable



PUMP TECHNICAL DATA

• Maximum working pressure: 10 bar
• Maximum temperature of the liquid: 40°C
• Maximum suction depth: 6 m
• G1frac14; suction and discharge connection
• MEI > 0,4



MOTOR TECHNICAL DATA

• Asynchronous motor cooled via the moving liquid
• Class of insulation F
• IP68 Protection degree
• 230V ±10%, 50Hz single-phase voltage, 400 ±10%, 50Hz three- phase voltage
• Permanent capacitor inserted and thermo-amperometric protection
with automatic rearm incorporated for the single phase motor
• Protection under user's responsibility for the three phase version



MATERIALS

• Pump casing, seal housing disc, external casing and motor cover in AISI 304
• Impeller and diffuser in PPE+PS reinforced with fibreglass
• Shaft in AISI 416
• Mechanical seal in Carbon/Ceramic/NBR

• Product Code: KSP
• Shipping: Free Delivery

Kingspan Tanks - Tail-lift deliveries are available for most tanks up to 2,000 Litre capacities for kerbside delivery.
It is the responsibility of the customer to inform us, if off-loading equipment is required.

Klargester Tanks  - All tanks are delivered on 45ft Flat-bed Articulated Trailers, so off-loading equipment on site is necessary.
HIAB off-loading is available at extra cost, if requested.
It is the responsibility of the customer to inform us, if off-loading equipment is required.

Harlequin Tanks  - Tail-lift deliveries are available for most tanks up to 2,500 Litre capacities for kerbside delivery subject to availability.
It is the responsibility of the customer to inform us, if off-loading equipment is required.

tanks.ie undertakes to attempt to fulfill all orders within a maximum of 7 working days of order acceptance, unless advised otherwise. In the event that any order is delayed, tanks.ie will not be responsible for any consequential loss or damage that this delay may cause.

Smaller items (including most accessories and consumables) will normally be despatched by courier.
Larger items (including all storage tanks) will normally be delivered by carrier.

Please note that for all items delivered by carrier, normally a truck + 40ft trailer, it is the customer's responsibility to ensure adequate vehicular access and to provide suitable offloading equipment, where required. Please notify us, if this might pose a problem and we will endeavour to facilitate your request.

ORDER CANCELLATION

In accordance with Irish and European Union consumer laws, you have seven days after receipt of order to cancel the order in its entirety or any part thereof, providing the goods are in a re-saleable condition. Should you wish to cancel any order, you must first contact sales@tanks.ie for a ‘Returns Authorisation Number’.

Please call 051 351325 or e-mail sales@tanks.ie


After the Returns Authorisation Number has been issued, we will make arrangements with you for the goods to be returned. If you wish tanks.ie to arrange the collection of the goods, please note that a carriage and administration charge will apply, which will not exceed 35% of the gross value of the goods.

Upon return of the cancelled goods to tanks.ie and verification that they are in a re-saleable condition, we will refund the value of the goods, less any collection and administration charges, within 28 days.

DEFECTIVE PRODUCTS

If you believe that products you have purchased from tanks.ie are defective, please report this immediately to tanks.ie by e-mail sales@tanks.ie or call 051 351325.

If they are within the manufacturer’s guarantee period, we will arrange with the manufacturer to replace or repair the goods at the manufacturer’s discretion and consistent with their guarantee.
Where it is necessary to inspect the goods on site and an inspection proves the fault is neither the fault of tanks.ie, nor the product manufacturer, an inspection charge will apply, which will be advised by the manufacturer prior to site inspection.

Please note that where guarantees are available in excess of those required by law, these are provided at the discretion of the product manufacturer and not tanks.ie. Additionally, tanks.ie will not be liable for any claims for consequential damage or loss.

Ebara Multigo M40/8
