Product Ref: TK48/4+TL48/4/100E

Made To Order Non-returnable Cylindrical Customer Off Loading, Free Delivery Customer Off Loading, Free Delivery

from €14,458.97 ex VAT
(€17,784.53 inc VAT)

Product Description


This 500,000 Litres Galvanised Steel Water Tank is a corrugated Galvanized steel water tank designed specifically to hold large quantities of water. The steel is approved to BS2989:1982 and is galvanized with lead free zinc to 275g/m² to EN10142. There is a minimum safety margin of 40% - this means that the structural strength of the tank is capable of holding a minimum of 40% more than the tanks actual volume. (It is not capable of holding more than the stated volume). The tanks are extremely strong and look aesthetically very pleasing.


  • Very Strong
  • Easy to install
  • Key design is flexibility of footprint and capacity - can be fitted into an existing plant/ civil layout
  • Photographic instruction manual provided
  • Cost effective solution to storing large quantities of water
  • Many sizes available - from 1.5m³ to 2000m³ and can also be supplied as linked tanks in a modular systems
  • Just two people can assemble
  • Portable, simple to move and reassemble
  • Effective - supplied in kit form for minimized transportation costs
  • Covers to suit any application: galvanised steel (with two hatches) or anti algae woven polypropylene
  • Minimum in-built 20% safety margin (40% for the TK range)
  • 10 Year Warranty on panels and liners



  • Storage of drinking water for emergency humanitarian aid
  • Rainwater harvesting for the recycling of water
  • Irrigation water for horticulture, nurseries and garden centres
  • Irrigation water for sports playing surfaces
  • Tanks for aquaculture
  • Dust suppression
  • Attenuation Tanks
  • Storage of water for dust suppression systems
  • Grey water storage


Included EPDM Liner:

Greenseal EPDM Irrigation Tank Lining Material 0.75mm - 1.00mm is a flexible robust material with excellent cut through, abrasion and UV resistance. EPDM offers a strong and more cost-efficient option than Butyl.

  • Colour: Matt Black
  • Abrasion Resistance: Excellent
  • Chemical Resistance: Good
  • Cut Through Resistance: Excellent
  • Flexibility: Very Flexible
  • Temperature Resistance: Very Good
  • UV Resistance: Excellent
  • Repair with Glue & patch


Other Options (please contact us for further information)

  • Various outlet options
  • Various inlet valve options
  • Access Ladder and Handrail Kit
  • Pipe enclosures
  • Platforms
  • Cast iron flanged gate valves

Tanks comes with all steel panels, nuts, bolts and washers, anchor kit, top and bottom tank capping, wire, strainer and EPDM liner as standard

Fire and Rescue Service Support Tanks (FRST)

These tank systems provide additional water storage capacity available as quick release hydrant outlet directly from the tank or locally positioned hydrants on the site.

The capacity required is defined by Fire Officers Site Risk Assessment and relates to the duration and flow rate required to support hydrant servicing fire engine or hose reels on site.

Water from the tank is drawn by suction pumps either on board the appliance (to replenish inbuilt tank on the tender) or on site.

The tank incorporates a vortex inhibitor system with maximum flow on standard 4” 110 mm hydrant outlets of 50.0 LPS - Litres / Sec (Higher Flow Rates by special design)

Site Certification and Licensing

The FRST tank provision assists with overall specification within the FRS Risk Assessment and allows Fire Certification by FO and Operational Licenses for the site by Local Authority and Environment Agency Site

Basic Tank Specification for FRST

  • Basic Galvanised Steel Tank and Roof / Cover – 1.0 mm EPDM Liner – 4” DN100 Hydrant outlet- Vortex Inhibitor. Cast Iron Gate Valve. Liquid Level Indicator.
  • Configured for site water fill requirements.
  • Optional Powder Coating Finish
  • Tank supplied with 10 year Warranty and Certificate of Conformity

Commonly supplied in 50,000 to 500,000 litres sizes.


Please note image of tank is for illustration purposes only

Delivery 3-4 weeks

Product Specification

  • Product Code: EV
  • Made To Order: Made To Order
  • Non-returnable: Non-returnable
  • Potable: No
  • Shape: Cylindrical
  • Shipping: Customer Off Loading, Free Delivery
  • Volume: 512500ltr
  • Dimensions: H:3.05mm
  • Diameter: 14.63mm

Delivery Terms

Kingspan Tanks - Tail-lift deliveries are available for most tanks up to 2,000 Litre capacities for kerbside delivery.
It is the responsibility of the customer to inform us, if off-loading equipment is required.

Klargester Tanks  - All tanks are delivered on 45ft Flat-bed Articulated Trailers, so off-loading equipment on site is necessary.
HIAB off-loading is available at extra cost, if requested.
It is the responsibility of the customer to inform us, if off-loading equipment is required.

Harlequin Tanks  - Tail-lift deliveries are available for most tanks up to 2,500 Litre capacities for kerbside delivery subject to availability.
It is the responsibility of the customer to inform us, if off-loading equipment is required.

tanks.ie undertakes to attempt to fulfill all orders within a maximum of 7 working days of order acceptance, unless advised otherwise. In the event that any order is delayed, tanks.ie will not be responsible for any consequential loss or damage that this delay may cause.

Smaller items (including most accessories and consumables) will normally be despatched by courier.
Larger items (including all storage tanks) will normally be delivered by carrier.

Please note that for all items delivered by carrier, normally a truck + 40ft trailer, it is the customer's responsibility to ensure adequate vehicular access and to provide suitable offloading equipment, where required. Please notify us, if this might pose a problem and we will endeavour to facilitate your request.

Returns Information


In accordance with Irish and European Union consumer laws, you have seven days after receipt of order to cancel the order in its entirety or any part thereof, providing the goods are in a re-saleable condition. Should you wish to cancel any order, you must first contact sales@tanks.ie for a ‘Returns Authorisation Number’.

Please call 051 351325 or e-mail sales@tanks.ie

After the Returns Authorisation Number has been issued, we will make arrangements with you for the goods to be returned. If you wish tanks.ie to arrange the collection of the goods, please note that a carriage and administration charge will apply, which will not exceed 35% of the gross value of the goods.

Upon return of the cancelled goods to tanks.ie and verification that they are in a re-saleable condition, we will refund the value of the goods, less any collection and administration charges, within 28 days.


If you believe that products you have purchased from tanks.ie are defective, please report this immediately to tanks.ie by e-mail sales@tanks.ie or call 051 351325.

If they are within the manufacturer’s guarantee period, we will arrange with the manufacturer to replace or repair the goods at the manufacturer’s discretion and consistent with their guarantee.
Where it is necessary to inspect the goods on site and an inspection proves the fault is neither the fault of tanks.ie, nor the product manufacturer, an inspection charge will apply, which will be advised by the manufacturer prior to site inspection.

Please note that where guarantees are available in excess of those required by law, these are provided at the discretion of the product manufacturer and not tanks.ie. Additionally, tanks.ie will not be liable for any claims for consequential damage or loss.
