BYPASS SEPARATOR NSBP4

BYPASS SEPARATOR NSBP4

BYPASS SEPARATOR NSBP4

Product Ref: 0014162

Underground Customer Off Loading, Free Delivery Customer Off Loading, Free Delivery

available Available

Choose option:

updown
from €1,131.00 ex VAT
(€1,391.13 inc VAT)
You may also need:
OILSET SEPARATOR ALARM
updown
OILSET SEPARATOR ALARM
€459.00 ex VAT
(€564.57 inc VAT)

Product Description

BYPASS SEPARATOR NSBP4


ByPass Separators fully treat all flows generated by rainfall rates of up to 6.5mm/hr. This covers over 99% of all rainfall events. Flows above this rate are allowed to bypass the separator. Each ByPass Separator design includes the necessary volume requirement for:-

  • Oil separation capacity
  • Silt storage capacity
  • Oil storage volume
  • Coalescer



Features and benefits

  • Light and easy to install, saving you time and money
  • Polyethylene Chamber Construction
  • Oil alarm system available (required by EN858-1 and PPG3)
  • Inclusive of silt storage volume
  • Fitted inlet/outlet connectors
  • Vent points within necks
  • Extension access shafts for deep inverts
  • Maintenance from ground level
  • CE-marked




Specification

  • Flowrate 4.5 l/s
  • Peak flowrate 45 l/s
  • Drainage area - 2500m2
  • Storage Capacity (litres) - Silt 450l / Oil 60l
  • Base to invert level - 1420mm
  • Base to outlet level - 1320mm
  • Min. Invert Inlet - 500mm
  • Standard pipework dia - 160mm
  • Standard fall across - 100mm



Compliance:

  • Fully compliant and tested to EN 858-1
  • Certified flow and process performance assessing effluent qualities to the requirements of EN 858-1
  • The unit is designed to treat the 'first flush' - 10% of peak flow. The calculated drainage areas served by each separator are indicated according to the formula NSB = 0.0018A(m2)
  • Class 1 separators are designed to achieve a concentration of less than 5mg per litre

bypass-separator-table



*DELIVERY TERMS

All tanks are delivered on 45ft Flat-bed Articulated Trailers, so off-loading equipment on site is necessary.

HIAB off-loading is available at extra cost, if requested.

It is the responsibility of the customer to inform us, if off-loading equipment is required.




Service and Maintenance:

It is essential that you ensure your separator is properly serviced and maintained to remain compliant with EN 858-1 standard and prevent pollution due to blockages. Kingspan's service and maintenance packages have been developed using their expert knowledge of their separators to help keep your separator operating at optimal efficiency, therefore remaining non-polluting and compliant. Visit Kingspan Service or contact the Kingspan Team on 0818 543 500 or for more information on the packages available.

Delivery Terms

Kingspan Tanks - Tail-lift deliveries are available for most tanks up to 2,000 Litre capacities for kerbside delivery.
It is the responsibility of the customer to inform us, if off-loading equipment is required.

Klargester Tanks  - All tanks are delivered on 45ft Flat-bed Articulated Trailers, so off-loading equipment on site is necessary.
HIAB off-loading is available at extra cost, if requested.
It is the responsibility of the customer to inform us, if off-loading equipment is required.

Harlequin Tanks  - Tail-lift deliveries are available for most tanks up to 2,500 Litre capacities for kerbside delivery subject to availability.
It is the responsibility of the customer to inform us, if off-loading equipment is required.

tanks.ie undertakes to attempt to fulfill all orders within a maximum of 7 working days of order acceptance, unless advised otherwise. In the event that any order is delayed, tanks.ie will not be responsible for any consequential loss or damage that this delay may cause.

Smaller items (including most accessories and consumables) will normally be despatched by courier.
Larger items (including all storage tanks) will normally be delivered by carrier.

Please note that for all items delivered by carrier, normally a truck + 40ft trailer, it is the customer's responsibility to ensure adequate vehicular access and to provide suitable offloading equipment, where required. Please notify us, if this might pose a problem and we will endeavour to facilitate your request.

Returns Information

ORDER CANCELLATION

In accordance with Irish and European Union consumer laws, you have seven days after receipt of order to cancel the order in its entirety or any part thereof, providing the goods are in a re-saleable condition. Should you wish to cancel any order, you must first contact [email protected] for a ‘Returns Authorisation Number’.

Please call 051 351325 or e-mail [email protected]


After the Returns Authorisation Number has been issued, we will make arrangements with you for the goods to be returned. If you wish tanks.ie to arrange the collection of the goods, please note that a carriage and administration charge will apply, which will not exceed 35% of the gross value of the goods.

Upon return of the cancelled goods to tanks.ie and verification that they are in a re-saleable condition, we will refund the value of the goods, less any collection and administration charges, within 28 days.

DEFECTIVE PRODUCTS

If you believe that products you have purchased from tanks.ie are defective, please report this immediately to tanks.ie by e-mail [email protected] or call 051 351325.

If they are within the manufacturer’s guarantee period, we will arrange with the manufacturer to replace or repair the goods at the manufacturer’s discretion and consistent with their guarantee.
Where it is necessary to inspect the goods on site and an inspection proves the fault is neither the fault of tanks.ie, nor the product manufacturer, an inspection charge will apply, which will be advised by the manufacturer prior to site inspection.

Please note that where guarantees are available in excess of those required by law, these are provided at the discretion of the product manufacturer and not tanks.ie. Additionally, tanks.ie will not be liable for any claims for consequential damage or loss.

Product Specification

  • Product Code: KLA
  • Shape: Underground
  • Shipping: Customer Off Loading, Free Delivery
  • Dimensions: D:1700mm
  • Diameter: 1350mm
