EcoBloc Soakaway Attenuation Crates 11m3

EcoBloc Soakaway Attenuation Crates 11m3

EcoBloc Maxx is manufactured from selected recycled material and is designed for attenuation of stormwater and storage of fire water for deeper applications which may be subject to regular and heavy traffic loadings, e.g. cars and HGV’s. These Ecobloc attenuation crates have three times the storage volume of a standard gravel infiltration ditch.

Benefits:

• Flexible modular design with unlimited capacity
• Shallow installation for projects with rock or water table on-site
• Modular system allows for independent cleaning while ensuring adequate volume
• Suitable for HGV loading up to 40t
• Combined with a Carat XXL or Platin XXL firefighting water tank for additional storage
• Easy access for inspection
• 50-year design life

Specification:

• Size 4.8m x 3.2m x 0.74 (6 crates wide x 4 crates long x 2 crate high) = 11.36m3
• Gross @ 96% Void ratio: 10.91m3
• Dimensions of one crate : 800 x 800 x 350mm
• Weight of one crate: 9 kg
• Gross volume of one crate: 225 litres
• Vertical load: 36.5 tonnes/m3 (365kN/m2)
• Lateral load: 10 tonnes/m2 (99.6kN/m2)
• BBA Approved 15/5200

Included:

• 24 x Base Plates
• 48 x Max Crates
• 20 sets(2) of End Plates
• 1 x Vent Adaptor
• 76 x Connectors
• 58.56m2 Geotextile

• Product Code: GRAF
• Colour: Black
• Fuel Type: Water
• Guarantee: 5 Year
• Shape: Underground
• Shipping: Customer Off Loading, Free Delivery
• Volume: 10416ltr
• Dimensions: L:3200mm W:4800mm H:740mm
