Product Ref: FSK100

Water Yes Free Delivery

€2,020.70 ex VAT
(€2,485.46 inc VAT)

Product Description


ESBE Fresh Hydro Units stands for outstanding performance in potable water installations. It is a modern and efficient way of potable water heating. The Fresh Hydro Hot Water Unit is designed for potable water applications. Equipped with unique hydro block, quick mixing actuator, two pass plate heat exchangers and intelligent controller the FSK100 series are one of a kind. These high sophisticated appliances provide outstanding potable water performance and temperature stability. The Fresh Hydro Unit works according to the flowrate principle and guarantees potable hot water (PHW) on demand, with stable and accurate temperature as well lowest stand by losses.

  • All time fresh, vital and hygienic hot water in the demanded volume
  • High tap rates
  • Fast reaction times
  • Lowest calcification risk
  • Legionella flushing function

Technical Data:

Tap performance: 40 l/min - at 70°C primary;
40 l/min - at 45°C outlet secondary
Plate, heat exchanger (plates): 41
Insulation: EPP
Weight: 20,0 kg
Working pressure, potable water: 1 MPa
Working pressure, heating: 300 kPa
Media, Heating water: in accordance with VDI2035
Media, Water/Glycol mixtures: max. 50 % (above 20% admixture, the pump data must be checked)
Media, Water/Ethanol mixtures: max. 28 %
Media temperature, max.: +95 °C
Media temperature, min.: +2 °C
Connection - Cold water (A): Internal thread G1", ISO 228/1
Connection - Warm water (B): Internal thread G1", ISO 228/1
Connection - Storage tank (C): External thread G1", ISO 228/1
Connection - Storage tank (D): External thread G1", ISO 228/1
Connection - Circulation (E): External thread G½", ISO 228/1
Connection - Flush connection (F): External thread G½", ISO 228/1

Product Specification

  • Product Code: ESBE
  • Fuel Type: Water
  • Outlet Size: 1''
  • Potable: Yes
  • Shipping: Free Delivery
  • Weight: 20.000kg
  • Dimensions: L:304mm W:400mm H:600mm
