ORB 2500 WASTE OIL TANK
ORB 2500 WASTE OIL TANK
2500L waste oil storage tank for safe collection and containment of used oil. Essential for workshop and fleet maintenance operations.
Estimate delivery costs
Your Eircode lets us show an accurate delivery cost before checkout.
Harlequin Manufacturing Ltd (Euro)
What makes this TANK the right choice?
ORB 2500 BUNDED WASTE OIL TANK
Harlequin bunded waste oil tanks have been engineered for the safe, secure and environmentally responsible storage of waste oils and lubricants. Their integrally bunded construction ensures they are ideal for even the most environmentally sensitive areas. All Harlequin waste oil tanks are supplied complete with large capacity tundish, removable strainer and optional tank contents gauge.
Comes with:-
- Large Capacity Tundish
- Lockable Lid
- Removable Strainer
- Environment Agency Oil Bank Graphics.
A contents gauge can be specified as an extra cost option on all Harlequin Waste Oil Tanks.
*DELIVERY TERMS:
Tail-lift deliveries are available for most tanks up to 2,500 Litre capacities but are subject to availability.
All tanks greater than 2,500 Litre capacities are delivered on 45ft. Flat-bed Articulated Trailers.
HIAB off-loading is available at extra cost for deliveries of tanks above 2,500 Litre capacities, if requested.
It is the responsibility of the customer to inform us, if off-loading equipment is required.
Technical data
Full specifications
| Physical | |
| Capacity | 2571 L |
| L × W × H | 246 × 144 × 158 cm |
| L × W × H (mm) | 2460 × 1435 × 1575 |
| Empty weight | 220 kg |
| Reference | |
| SKU | ORB2500 |
| EDEL code | EDELP00002251 |
Irish regulations
Installation & requirements
OFTEC regulation
All domestic oil tank installations in Ireland must be carried out by an OFTEC-registered technician. The tank must conform to IS:293 and be sited in accordance with IS:820.
Site requirements
The tank must stand on a level, load-bearing concrete base minimum 100 mm thick, extending 300 mm beyond the tank footprint on all sides. Ground must be clear of vegetation.
Bunding requirements
Bunded tanks are required within 10 m of a watercourse or drain. Secondary containment must hold 110% of the inner tank capacity. Check local planning conditions before installation.
Technical documentation
Downloads & data sheets
