PIUSI K33 ATEX MECHANICAL FLOW METER

PIUSI K33 ATEX MECHANICAL FLOW METER

Product Ref: F00570000

Petrol Free Delivery

updown
€251.43 ex VAT
(€309.26 inc VAT)

PIUSI K33 ATEX MECHANICAL FLOW METER

The Piusi K33 ATEX Mechanical flow meter is designed to measure the exact quantity of gasoline, diesel or kerosene in a potentially explosive environment.
Able to measure up up 999.9 litres at a time and easy to install and calibrate, the ATEX approved K33 flow meter is a flexible petrol and diesel flow meter. These Piusi fuel flow meters can be implemented in either rigid or flexible pipe lines, or installed directly onto the pump. Reliable, economical and easy to install and calibrate on site. Also gravity functional thanks to reduced resistance to flow.

Flow meters are essential for measuring quantities dispensed, and professionals need precise, reliable, robust instruments. Piusi's response to these requirements is a comprehensive range of digital and mechanical flow meters, some of which stand out for their light weight and precision, and others for their strength and reliability. Piusi flow meters can be used for the widest imaginable range of applications, including for diesel, oil and foodstuffs.

Our range of flow meters also includes models designed for the most demanding situations: for example, we have high flow-rate flow meters and pulser flow meters which read the flow rate of the liquid and display the results on remote screens. This solution is particularly useful on trucks and earthmoving machinery, for example.

Mod. K33, 3 digit display. (max 999 litres), 6 digit totals.
Flow rate of 20 to 120 litres per minute.


Specification:


  • Diesel, kerosene and petrol flow meter
  • Can be rotated to allow flow from 4 directions
  • 3 digit resettable and 6 digit non-resettable totaliser
  • Flow rate: 20-120ltr Per Min
  • 1' F x F BSP Inlet/Outlet
  • Accuracy +/-1% after calibration
  • Nutating disk system
  • ATEX certified to 2 G IIB T=85 deg C (T6)
  • Operating pressure 3.5 bar
  • Bursting pressure 28 bar







Product Specification

  • Product Code: ROT
  • Fuel Type: Petrol
  • Outlet Size: 1" F x F BSP Inlet/Outlet
  • Shipping: Free Delivery
  • Weight: 0.600kg
  • Dimensions: D:180mm W:180mm

Delivery Terms

Kingspan Tanks - Tail-lift deliveries are available for most tanks up to 2,000 Litre capacities for kerbside delivery.
It is the responsibility of the customer to inform us, if off-loading equipment is required.

Klargester Tanks  - All tanks are delivered on 45ft Flat-bed Articulated Trailers, so off-loading equipment on site is necessary.
HIAB off-loading is available at extra cost, if requested.
It is the responsibility of the customer to inform us, if off-loading equipment is required.

Harlequin Tanks  - Tail-lift deliveries are available for most tanks up to 2,500 Litre capacities for kerbside delivery subject to availability.
It is the responsibility of the customer to inform us, if off-loading equipment is required.

tanks.ie undertakes to attempt to fulfill all orders within a maximum of 7 working days of order acceptance, unless advised otherwise. In the event that any order is delayed, tanks.ie will not be responsible for any consequential loss or damage that this delay may cause.

Smaller items (including most accessories and consumables) will normally be despatched by courier.
Larger items (including all storage tanks) will normally be delivered by carrier.

Please note that for all items delivered by carrier, normally a truck + 40ft trailer, it is the customer's responsibility to ensure adequate vehicular access and to provide suitable offloading equipment, where required. Please notify us, if this might pose a problem and we will endeavour to facilitate your request.

Returns Information

ORDER CANCELLATION

In accordance with Irish and European Union consumer laws, you have seven days after receipt of order to cancel the order in its entirety or any part thereof, providing the goods are in a re-saleable condition. Should you wish to cancel any order, you must first contact [email protected] for a ‘Returns Authorisation Number’.

Please call 051 351325 or e-mail [email protected]


After the Returns Authorisation Number has been issued, we will make arrangements with you for the goods to be returned. If you wish tanks.ie to arrange the collection of the goods, please note that a carriage and administration charge will apply, which will not exceed 35% of the gross value of the goods.

Upon return of the cancelled goods to tanks.ie and verification that they are in a re-saleable condition, we will refund the value of the goods, less any collection and administration charges, within 28 days.

DEFECTIVE PRODUCTS

If you believe that products you have purchased from tanks.ie are defective, please report this immediately to tanks.ie by e-mail [email protected] or call 051 351325.

If they are within the manufacturer’s guarantee period, we will arrange with the manufacturer to replace or repair the goods at the manufacturer’s discretion and consistent with their guarantee.
Where it is necessary to inspect the goods on site and an inspection proves the fault is neither the fault of tanks.ie, nor the product manufacturer, an inspection charge will apply, which will be advised by the manufacturer prior to site inspection.

Please note that where guarantees are available in excess of those required by law, these are provided at the discretion of the product manufacturer and not tanks.ie. Additionally, tanks.ie will not be liable for any claims for consequential damage or loss.

Downloadable Documents

pdfPIUSI-K33-ATEX_EN_1_
