PIUSI K600/3 DIESEL PULSE METER

Piusi PIUSI K600/3 DIESEL PULSE METER

PIUSI K600/3 DIESEL PULSE METER

Product Ref: F00472A00

Diesel Free Delivery

available Available

updown
€250.43 ex VAT
(€308.03 inc VAT)
Product Description

PIUSI K600/3 DIESEL PULSE METER

The Piusi K600/3 digital fuel flow meter measures the quantity of diesel delivered, with a maximum flow rate of 100 lpm.The oval gear pulse meters are designed to meet a wide range of product delivery measuring requirements in the private distribution of fuel, lubricant and low, medium and high viscosity liquids. The oval gear measuring principle adopted offers high precision and low pressure losses.

Easy interfacing with control systems makes the Piusi K600/3 pulse flow meter is the ideal solution for equipping fuel delivery pumps for private use in stationary lubricant transfer/delivery systems, as fuel meters for tank filling arms, for control of burner or power unit fuel consumption and other industrial applications requiring fluid delivery control.


Performance:-

  • Flow rate 10 - 100 l/min
  • Fluid viscosity 2 - 5.35
  • Pulses per litre 35
  • 1” F BSP Flanged Inlet/Outlet
  • Oval gear system
  • Accuracy +/-0.5% after calibration
  • Inlet filter



Construction features:-


  • Body with aluminium measuring chamber
  • Oval gears made of acetalic resin
  • Aligned inlet/outlet apertures provided with female thread
  • Integrated suction filter



Delivery Terms

Kingspan Tanks - Tail-lift deliveries are available for most tanks up to 2,000 Litre capacities for kerbside delivery.
It is the responsibility of the customer to inform us, if off-loading equipment is required.

Klargester Tanks  - All tanks are delivered on 45ft Flat-bed Articulated Trailers, so off-loading equipment on site is necessary.
HIAB off-loading is available at extra cost, if requested.
It is the responsibility of the customer to inform us, if off-loading equipment is required.

Harlequin Tanks  - Tail-lift deliveries are available for most tanks up to 2,500 Litre capacities for kerbside delivery subject to availability.
It is the responsibility of the customer to inform us, if off-loading equipment is required.

tanks.ie undertakes to attempt to fulfill all orders within a maximum of 7 working days of order acceptance, unless advised otherwise. In the event that any order is delayed, tanks.ie will not be responsible for any consequential loss or damage that this delay may cause.

Smaller items (including most accessories and consumables) will normally be despatched by courier.
Larger items (including all storage tanks) will normally be delivered by carrier.

Please note that for all items delivered by carrier, normally a truck + 40ft trailer, it is the customer's responsibility to ensure adequate vehicular access and to provide suitable offloading equipment, where required. Please notify us, if this might pose a problem and we will endeavour to facilitate your request.

Returns Information

ORDER CANCELLATION

In accordance with Irish and European Union consumer laws, you have seven days after receipt of order to cancel the order in its entirety or any part thereof, providing the goods are in a re-saleable condition. Should you wish to cancel any order, you must first contact [email protected] for a ‘Returns Authorisation Number’.

Please call 051 351325 or e-mail [email protected]


After the Returns Authorisation Number has been issued, we will make arrangements with you for the goods to be returned. If you wish tanks.ie to arrange the collection of the goods, please note that a carriage and administration charge will apply, which will not exceed 35% of the gross value of the goods.

Upon return of the cancelled goods to tanks.ie and verification that they are in a re-saleable condition, we will refund the value of the goods, less any collection and administration charges, within 28 days.

DEFECTIVE PRODUCTS

If you believe that products you have purchased from tanks.ie are defective, please report this immediately to tanks.ie by e-mail [email protected] or call 051 351325.

If they are within the manufacturer’s guarantee period, we will arrange with the manufacturer to replace or repair the goods at the manufacturer’s discretion and consistent with their guarantee.
Where it is necessary to inspect the goods on site and an inspection proves the fault is neither the fault of tanks.ie, nor the product manufacturer, an inspection charge will apply, which will be advised by the manufacturer prior to site inspection.

Please note that where guarantees are available in excess of those required by law, these are provided at the discretion of the product manufacturer and not tanks.ie. Additionally, tanks.ie will not be liable for any claims for consequential damage or loss.

Product Specification

  • Product Code: ROT
  • Fuel Type: Diesel
  • Shipping: Free Delivery
  • Weight: 2.600kg
  • Dimensions: D:200mm W:120mm
