BATTERY MULTI-ZONE TANK ALARM

The Battery Operated Multi-Compartment Fuel Tank Alarm system has three functions; to detect and warn of a fuel storage tank overfill, a high/low liquid level and a bund leak. If the tank level alarm identifies that any of these states have occured, the zone in question will illuminate on the alarm’s screen, and a loud siren and flashing red light will go off. When its battery is low, this level bund alarm will sound a single beep every minute to alert the user of this.

Thanks to being battery powered, these fuel tank alarms are designed to be installed on isolated or portable systems, and each zone can be configured allowing the alarm to be customised by the installer. An option is available that comes with three relays, allowing additional equipment to be connected to the tank level alarm such as larger alarm systems or building management systems for remote monitoring.

If you need a tank level alarm for a fluid other than diesel or light oil, also available are a water and chemical alarm probe, and a high viscosity oil tank level probe – which is also suitable for AdBlue as well as high viscosity oils.

Please note: The probes required do not come as standard with the fuel tank alarm box. Please view the accessories to select the combination you need.

Specification:

• Battery multi-channel tank alarm for alerting of a combination or all of the following tank states: high, low and/or bund
• Designed for isolated or portable installations where mains power is unavailable
• 90db sounder & flashing orange strobe to warn of a problem
• Zone in question lights up on the screen to clearly indicate the activated tank state
• Test & alarm mute functions
• Automatically reversed float logic for low zones
• Weatherproof IP55 enclosure
• Low battery warning - will sound a single beep every minute
• Option with relays to connect to external equipment e.g other alarms or building management systems for remote monitoring
• Version with relays can also be used to control the pump operation on a day tank
• 6 x 9v AA Batteries
