DIESEL DISPENSING STATION HDM 60 ECO BOX

DIESEL DISPENSING STATION HDM 60 ECO BOX

Product Ref: 110700960

Free Delivery

available Available

updown
from €1,492.00 ex VAT
(€1,835.16 inc VAT)
You may also need:
Transponder Tag
updown
Transponder Tag
€25.27 ex VAT
(€31.08 inc VAT)

Product Description

DIESEL DISPENSING STATION HDM 60 ECO BOX


The HDM Eco Series is a high performance diesel dispenser and pumping system with an integrated fuel management system, specially developed for fleets and non-public filling stations. Designed for economy, reliability and simplicity of use, the HDM 60 Eco Box is manufactured to meet the needs of demanding applications and provides the operator with easy to read dispensed fuel data.

This fuel management system can be used by up to 2,000 different drivers and vehicles and its advanced technology using a USB interface enables the quick and easy transfer of data.

This diesel dispensing station is fast and reliable refueling.

This fuel management systems safety features include drip tray and leak detection



Description:


  • Identification via transponder technology
  • USB interface for data transfer
  • Includes drip tray and leakage monitoring
  • Rotary vane pump with asynchronous motor
  • Oval gear meter with pulser
  • Discharge hose 4 m DN 19, with type-approved automatic nozzle A 2010, discharge nozzle holder
  • Suction line min. DN 32
  • Robust powder-coated steel housing
  • Two-line LC-Display, illuminated, 8 or 19 mm digit height
  • Saves up to 2,000 filling data sets
  • Standard languages: English, German, French



Specifications:









  • Flow rate 55 L / Min
  • Suction height 3.5 m
  • Discharge hose DN 19 x 4 m
  • Tap count 1
  • Connection: suction side G 1"
  • Accuracy ± 0.5%
  • Ambient Temperature -20 / +55 deg C
  • Medium temperature -10 / +35 deg C
  • Power supply voltage (electrical)230 v /50 Hz
  • Dimensions (W x D x H)553 x 380 x 470 mm
  • Weight 29 kg



Optional Installation Kit includes:


  • Mounting bracket for HDM Eco Box
  • 2 x 1" BSP Straight Nipple
  • 1 x 1" BSP Union
  • 1 x 1" BSP Non-return Valve
  • 1 x 1/4" BSP x 6m Tubing Return Line
