CUBE 56 DIESEL FUEL DISPENSER

CUBE 56 DIESEL FUEL DISPENSER

CUBE 56 DIESEL FUEL DISPENSER

Product Ref: 0005700C

Diesel Free Delivery

available Available

updown
€468.43 ex VAT
(€576.17 inc VAT)
Downloadable documents

pdfPIUSI-CUBE-56-70-90-esr

Product Description

CUBE 56 DIESEL FUEL DISPENSER


The Piusi Cube 56 diesel transfer pump is an Italian manufactured, market leading refuelling pump developed for the distribution of diesel fuel for non-commercial, private uses. This fully enclosed, Piusi electric fuel transfer pump unit comes complete with meter, nozzle and hose, allowing the fast, safe refuelling of vehicles, as well as the measuring of the quantities of fuel dispensed. The incorporated fuel flow meter in this Piusi diesel pump has a well-constructed mechanical display with a proven track record in reliability and ease of use. This diesel fuel transfer pump also has an in-built nozzle holder with pump start/stop lever, making operation an easy process.

Simple and versatile, Cube 56 diesel transfer pumps can also be installed on drums, thanks to the optional 2' quick coupling, or can be mounted freestanding using a pedestal. There is also a wall support kit available to enable the fitting of this Piusi fuel dispenser onto a wall or side of a tank.

The Cube 56 Diesel Fuel Dispenser is a sturdy design for various applications: can be fixed to walls, tanks, drums and special pedestals.

The diesel pump dispenses diesel at 56 litres per minute. Suitable for dispensing low-sulphur diesel with 7% bio-fuel content.The self-priming vane pump is fitted with bypass and is installed on anti-vibration supports.



Specification:-


  • Fully Enclosed Fuel Dispenser
  • Automatic nozzle with swivel connection
  • Integrated nozzle holder with start/stop pump lever
  • Intake mesh filter
  • Protection Grade: IP55 (Internal Motor)
  • On / Off Switch - Controlled By Nozzle
  • Flow rate 56l/min
  • 230 Volt AC/DC
  • Panther 56 Diesel Pump
  • K33 Flow meter
  • 1' BSP Inlet
  • 4m x 3/4' Hose
  • Noise level below 75dB
