DIESEL DISPENSING STATION HDM 60 ECO BOX

  • W50 II rotary vane pump with asynchronous motor
  • Fuel management system with PC software
  • Saves up to 10000 data records
  • Identification via transponder technology - pin code tag or card
  • Includes USB interface for easy data transfer

Availability: In stock

€1,426.39 + vat €1,754.46 incl vat
(Price includes delivery within Republic of Ireland)

Details

DIESEL DISPENSING STATION HDM 60 ECO BOX

The HDM Eco Series is a high performance diesel dispenser and pumping system with an integrated fuel management system, specially developed for fleets and non-public filling stations. Designed for economy, reliability and simplicity of use, the HDM 60 Eco Box is manufactured to meet the needs of demanding applications and provides the operator with easy to read dispensed fuel data.
This fuel management system can be used by up to 2,000 different drivers and vehicles and its advanced technology using a USB interface enables the quick and easy transfer of data.
This diesel dispensing station is fast and reliable refueling.
This fuel management systems safety features include drip tray and leak detection

Description:
  • Identification via transponder technology
  • USB interface for data transfer
  • Includes drip tray and leakage monitoring
  • Rotary vane pump with asynchronous motor
  • Oval gear meter with pulser
  • Discharge hose 4 m DN 19, with type-approved automatic nozzle A 2010, discharge nozzle holder
  • Suction line min. DN 32
  • Robust powder-coated steel housing
  • Two-line LC-Display, illuminated, 8 or 19 mm digit height
  • Saves up to 2,000 filling data sets
  • Standard languages: English, German, French


Specifications:
  • Flow rate 55 L / Min
  • Suction height 3.5 m
  • Discharge hose DN 19 x 4 m
  • Tap count 1
  • Connection: suction side G 1"
  • Accuracy ± 0.5%
  • Ambient Temperature -20 / +55°C
  • Medium temperature -10 / +35°C
  • Power supply voltage (electrical)230 v /50 Hz
  • Dimensions (W x D x H)553 x 380 x 470 mm
  • Weight 29 kg


Optional Installation Kit includes:
  • Mounting bracket for HDM Eco Box
  • 2 x 1" BSP Straight Nipple
  • 1 x 1" BSP Union
  • 1 x 1" BSP Non-return Valve
  • 1 x 1/4" BSP x 6m Tubing Return Line


Dimensions
Tankology Link /knowledgebase/article/horn-tecalemit-transfer-pumps/
Diameter No
Capacity (litres) No
Inlet invert (mm) No
Lid size (mm) No
Empty plant weight (kg) No
Length: 553
Width: 380
Height: 470
Weight: 29
Actual Capacity No
Nominal Capacity: No
