BIOFICIENT + 2 SEWAGE TREATMENT PLANT (10 POP)

BIOFICIENT + 2 SEWAGE TREATMENT PLANT (10 POP)

The BioFicient + 2 Sewage Treatment Plant has been specially designed for shallow dig applications, allowing for an unobtrusive below ground installation. Its unique design features include its low profile and extension neck, saving on-site time and expense. The Bioficient + 2 Sewage Treatment Plant is a highly economical and reliable solution for your sewage treatment needs. With low running costs, the Bioficient + Sewage Treatment Plant is easy to maintain. For added peace of mind, we offer a warranty period of 3 years*. Terms and conditions apply – please visit Warranty Terms.


Features and benefits

• Suitable for population equivalent of 10
• Material: Plastic/ GRP
• Outlet Level :800 - 1,600mm
• Pipework Diameter :110mm
• Cover size 700mm dia
• Blower Rate - 95W
• Shallow dig
• Low energy consumption
• Monitor with control panel
• Easy to set up and operate
• Minimal visual impact - low profile covers
• Excellent ammonia reduction (0.4mg/l)
• Installation in trafficked areas (structural design advice required by others)
• Saving on-site installation time
• EN 12566-3 tested and approved
• Fully CE marked in line with the CPR 2013
• Designed in compliance with the EPA Code of Practice

How the BioFicient + works


1) Wastewater and sewage flows into the primary settlement tank where solids are settled out and retained. Settled sewage is displaced from primary zone and enters the aerated media reactor (Biozone).

2) Solids are broken down by air agitated media in the Biozone. Media and liquid circulation in the Biozone is achieved through the use of a compressor and diffuser, which introduces fresh air into each compartment. The liquor is constantly recirculated and contacts the moving media and as it does so, it is purified by the micro organisms growing on the surface of the media and within the moving liquor. Excess growth of biomass is shed as solid particles into the liquor.

3) The final settlement tank is where fine solids form to sludge. At preset intervals, portions of the sludge and liquor are returned to the primary tank for additional treatment. The primary and final settlement zones should be emptied of sludge every 12 months.

4) Final effluent is discharged from the final settlement tank. With regulator approval, it is suitable for discharge to a watercourse or drainage field.

Performance and Compliance:

• BS EN 12566 Part 3 tested and approved
• Fully marked in line with the CPR 2013

Applications:

• Single / Multiple homes
• Barn conversions
• Small office developments
• Farms
• Stable yard toilet
• Offices/Light industrial premises

*DELIVERY TERMS

All tanks are delivered on 45ft Flat-bed Articulated Trailers, so off-loading equipment on site is necessary.

HIAB off-loading is available at extra cost, if requested.

It is the responsibility of the customer to inform us, if off-loading equipment is required.

 WOULD YOU LIKE A SITE ASSESSMENT DONE?

Before you purchase your sewage treatment system you may need advice on which system is suitable. From percolation tests and site assessments to specifiying the correct sewage treatment plant for installation we can help you through the process. If you would like our help, please click on Site Assessment Report and fill out the form  and we can take it from there.

Kingspan offer a commissioning and maintenance service on all their wastewater products. Your service and maintenance visit will include; system integrity and operation, check of all moving parts, effluent quality, flow rates, discharge consents and management system checks.

DO YOU REQUIRE COMMISSIONING?

To ensure your system operates to maximum efficiency, we recommend tried and tested commissioning by Klargesters own trained engineers.
Our unrivalled knowledge means that we are best placed to carry out bespoke assessments to get your system up and running. The commissioning will also provide you with a unique checklist against your system, ensuring your complete peace of mind and reassurance that your system's mechanical and electrical components are in good working order.

WHAT'S INCLUDED IN THE COMMISSIONING? CLICK HERE FOR MORE INFORMATION

For more information download the information below, call 0818 543 500 or go to Kingspan Service

Further sizes are available on request

• Product Code: KLA
• Fuel Type: Sewage
• Lid size: 700
• Shape: Underground
• Shipping: Customer Off Loading, Free Delivery
• Volume: 5585ltr
• Dimensions: L:3189mm
• Diameter: 2010mm
